● Introduction: The Question That Actually Matters
● What Total Cost Really Means in CNC Work
● In-House Costs – The Detailed Breakdown
● Outsourcing Costs – More Than the Hourly Rate
● Three Real Shops That Ran the Numbers
● Framework You Can Take Back to Your Shop Tomorrow
● Factors That Move the Crossover Point
● The Hybrid Strategy Most Shops Eventually Land On
● Conclusion: Run Your Own Numbers, Then Run Them Again Next Year
● Q&A: Questions I Get Every Time I Present This
Every manufacturing engineer has run into it: the spreadsheet that compares buying another machining center against keeping the work outside. The numbers never quite add up the same way twice because most of the templates floating around the internet stop at machine payment and hourly rate. In the real world, the decision usually comes down to cash flow, headaches, and whether you can sleep at night when a key supplier calls in sick for three weeks.
The gap between the quoted outsourcing rate and the true internal cost has narrowed in some areas and widened in others since 2020. Labor rates for qualified machinists keep climbing, new machines have higher sticker prices but lower operating costs per hour, and supply-chain disruptions made everyone rethink single-source offshore shops. This article lays out the full cost picture using data from shops that have already made the jump one way or the other.
Direct cutting time is usually the smallest slice of the pie. On typical prismatic aluminum parts in batches of 50–500 pieces, spindle time can be 12–18 % of the total cost once you load everything in. The rest lives in setup, programming, inspection, tooling, scrap, and the cost of money tied up in a half-finished billet that has been sitting on the floor for two weeks.
Floor space is expensive once you assign a real dollar value to it. A new 5-axis with bar feeder and pallet pool can easily eat 600 square feet including clearance and tool storage. At $12–$18 per square foot per year in most industrial parks, that is another $7,000–$10,000 a year that never shows up on the machine quote.
Coolant management and chip handling are another silent killer. A decent coolant filtration system for a titanium cell runs $80,000 upfront and $15,000 a year to keep clean. Shops that ignore this end up replacing pumps and ruining tools faster than the budget predicts.
A 2024 Haas VM-3 with 4th axis, through-spindle coolant, and probing lists at about $145,000 delivered. A comparable Brother Speedio with pallet changer is $165,000. Mid-level Japanese 5-axis machines (OKK, Matsuura, DMG) start at $420,000 and climb fast from there.
Straight-line depreciation over seven years is the accounting answer, but utilization drives the real hourly rate. At 1,000 hours per year the depreciation alone is $59/hour on a $420,000 machine. Push that same machine to 3,500 hours per year on two shifts and the number falls to $17/hour. That swing is larger than most outsourcing rate differences.
The median fully burdened rate for a setup machinist who can also program in Fusion 360 or Mastercam is $42–$48/hour in the Midwest and Southeast, $55–$65/hour on the coasts (2025 numbers). Add a programmer who only writes code and proves out 5-axis toolpaths and you're at $75–$90/hour burdened.
The fixed nature of that labor is what hurts. If the work drops 30 % for four months, the outsourcing shop lays off contract help or slows down. Your in-house people still draw salary.
Carbide pricing has stabilized after the 2021–2023 spike, but indexable tooling for Inconel and titanium is still 40–60 % higher than 2019. A single 50 mm face mill body with six inserts for 718 can top $1,200, and inserts are $65 each. Shops cutting hard materials routinely budget $18–$25 per hour in tooling on 5-axis work.
Most builders quote 3–5 % of machine value per year for preventive maintenance contracts. Real-world experience on machines running two shifts: budget 7–9 % once you include spindle rebuilds, ball-screw replacements, and the occasional cracked casting from a crash.
A typical 3-axis shop in the U.S. quotes $72–$92/hour for 6061 aluminum in 2025. 5-axis shops with good reputation quote $135–$185/hour for stainless and titanium. Those numbers are the starting point.
Actual adders on a medium-complexity part:
Setup fee: $350–$900 per new part number
Programming charge: $110–$160/hour if they do it
Material markup: 18–32 %
Debit for design changes after release: common
Expedite fee to jump the queue: 25–50 % premium
Freight both ways plus packaging
The $85/hour shop can land at $140–$160/hour once the part is in your dock and accepted.
A dimension missed by 0.012 mm because the shop took “break sharp edges” literally can scrap an entire assembly downstream. The average cost of one outsourced quality escape in aerospace-related supply chains runs $8,000–$25,000 once you count inspection, rework, expedited shipping, and line-down charges.
Annual outsourced spend on titanium airframe fittings: $2.1 million at $178/hour average.Investment: two Matsuura MX-520 machines plus dedicated cell ($1.65 million total installed).Year-one pain: high scrap, long cycle times learning.Year-three result: fully loaded cost $88/hour, lead time down from 14 weeks to 10 days, zero late deliveries. Payback reached at month 19.
Needed 8–60 pieces per revision on complex surgical instruments.Internal quote for a used Robodrill + programming bandwidth: $580,000 upfront.Outsourced route through three qualified shops: average landed cost $162/hour, total program spend $410,000 over 18 months. Machine would have run <9 % utilized.
Runs 14 older Haas VF series on carbon steel high-runners (72 % of hours).Outsourced all stainless manifolds and aluminum castings that need simultaneous 5-axis.Result: overall machining cost 22 % below industry average while maintaining <2 % late deliveries.
Step 1 – List every part number you currently outsource and total annual hours by machine class (3-axis, 4-axis, 5-axis, turning).Step 2 – Pull the real outsourced landed cost per hour including all fees and freight.Step 3 – Build the in-house hourly rate at 60 %, 80 %, and 100 % utilization scenarios. Include real burdened labor, tooling history, and facility allocation.Step 4 – Add capital recovery over 7–10 years and one-time tooling/fixturing costs amortized over expected life.Step 5 – Run the crossover chart. Most companies find the switch point between 1,600 and 2,400 hours per year for 3/4-axis work, 1,000–1,500 hours for true 5-axis.
Higher material difficulty (titanium, Inconel) pushes the break-even down because outsourcing premiums are huge.Tight tolerances (±0.0005″ or surface finish Ra 16) also favor in-house once volume justifies it.Frequent design changes or short lead-time demands almost always favor keeping the work inside.
Annual hours per machine platform exceed 2,000 and are stable year-to-year
Material or tolerance requirements command 50–100 % premiums outside
IP or ITAR restrictions make outsourcing painful or impossible
You already run two shifts on similar equipment
Under 1,200 hours per year on any given platform
Highly variable demand (seasonal or program-driven)
You need capabilities you don't have and don't plan to own (large horizontal boring, Swiss, gun-drilling, etc.)
Prototype or bridge production before production ramps
The companies with the best cost position and delivery performance run 60–75 % of their hours in-house on high-volume or critical-path work and outsource the rest strategically. They treat outsourcing relationships like an extension of their own capacity rather than a necessary evil.
There is no permanent answer. The right mix in 2023 often looks expensive or risky by 2025. Material prices, labor availability, customer forecast accuracy, and competitor moves all shift the curve.
The shops that stay ahead treat machining capacity decisions the same way they treat product design reviews – scheduled, data-driven, and willing to change direction when the facts change. Build the full total-cost model once, update the inputs every 12–18 months, and you'll make fewer million-dollar mistakes.
Q1: What annual outsourcing spend triggers a serious in-house review?
A: Anything north of $400,000–$500,000 on work that fits one machine platform deserves a hard look.
Q2: How do you convince finance that 65 % utilization is realistic?
A: Show them the last three years of outsourced purchase orders converted to spindle hours. Most engineers overestimate first-year utilization by 30–50 %.
Q3: Is it ever smart to buy a machine just for overflow?
A: Almost never. Overflow isn't predictable enough to pay the fixed costs.
Q4: How much does reshoring pressure affect the math?
A: It has pushed a lot of work back in-house for lead-time and quality reasons even when pure dollar cost was slightly higher.
Q5: What's the fastest way to kill an in-house justification?
A: Using accounting depreciation and fully absorbed overhead rates instead of the incremental cash cost of adding one more machine and one more operator.
