Surface treatments play a key role in determining how long CNC-machined parts last and how well they perform under load. The surface left after milling, turning, or grinding often contains small defects—tool marks, burrs, micro-cracks, or tensile residual stresses. These features act as starting points for failure when the part sees repeated stress, friction, or corrosive conditions. Applying the right post-machining treatment can close those weak spots, add hardness, or build a protective layer. The result is a component that runs longer, handles higher loads, and costs less to replace.
This article covers the main treatment families, the failure modes they address, and the data that back up their use. Examples come from steel shafts, aluminum brackets, titanium fittings, and other common CNC workpieces. The goal is to give engineers a clear path from surface condition to service life, with numbers and test methods that can be repeated in a lab or on the shop floor.
Grinding removes the peaks left by the cutting tool and leaves a controlled roughness. A ground 4140 steel shaft typically drops from 1.6 µm Ra to 0.4 µm Ra in one pass with a 60-grit wheel. That change cuts sliding friction by roughly 25 % in oil-lubricated tests. Honing takes the next step for bores; cross-hatch patterns hold oil and keep pressure films stable.
Shot peening drives small steel or ceramic media into the surface at 40–60 m/s. The impact plastically deforms the top 0.2–0.5 mm and leaves compressive stress. A peened 4340 axle journal shows a –550 MPa residual layer when measured with X-ray diffraction. Fatigue life under bending rises from 8 × 10⁵ cycles to 1.3 × 10⁶ cycles at the same stress amplitude.
Vibratory finishing and drag finishing round edges and remove burrs in bulk. A batch of 200 aluminum housings finished for 4 hours in ceramic media reaches 0.8 µm Ra and eliminates sharp corners that would otherwise chip under assembly loads.
Anodizing grows an aluminum oxide layer 10–25 µm thick. Type II gives color and mild corrosion protection; Type III (hard anodize) reaches 50 HV above the base 70 HV of 6061-T6. Salt-spray exposure for 500 hours leaves no pitting on hard-anodized panels, while untreated panels pit in 48 hours.
Electropolishing dissolves 10–20 µm of metal in a phosphoric-acid bath. Peaks dissolve faster than valleys, so Ra falls from 0.9 µm to 0.15 µm on 316L stainless. The process also strips the smeared layer left by turning, exposing clean grain boundaries.
Passivation in 20 % nitric acid rebuilds the chromium oxide film on stainless steels. A 30-minute dip is enough for machined valve bodies to pass 1000-hour humidity cabinet tests without rust.
Nitriding diffuses nitrogen into the surface of alloy steels at 500–550 °C. A 20-hour cycle on 4340 produces a 0.3 mm case with 900 HV hardness. Wear volume against a hardened counterface drops by a factor of three in pin-on-disk tests at 100 N load.
PVD TiN coatings add 2–3 µm of 2300 HV material. Cutting speed on coated carbide inserts rises 40 % before flank wear reaches 0.3 mm. DLC coatings on aluminum slideways lower the coefficient of friction to 0.08 and extend scuff-free life in dry running.
Thermal spray of WC-Co onto drill-bit faces builds a 200 µm layer that resists abrasive sand. Field hours in mining increase from 60 to 180 before edge rounding exceeds 0.5 mm.
Fatigue cracks start at surface defects under cyclic tension. Tensile residual stress from machining adds to the applied load and accelerates initiation. Compressive treatments reverse the stress state. A ground-and-peened 4340 steel specimen tested at 450 MPa alternating stress lasts 4.2 × 10⁵ cycles; the ground-only version fails at 2.8 × 10⁵ cycles. Crack growth rate measured by potential drop falls from 8 × 10⁻⁸ m/cycle to 3 × 10⁻⁸ m/cycle in the peened layer.
Adhesive wear removes material when asperities weld and shear. Hard coatings raise the shear strength. A nitrided gear tooth loses 0.012 mm³ per 10⁶ revolutions against a case-hardened pinion; the untreated tooth loses 0.045 mm³ under the same 800 N contact load.
Abrasive wear cuts grooves with hard particles. WC-Co overlays on conveyor screws reduce depth of cut from 0.8 mm to 0.25 mm after 500 hours of coal transport.
Pitting creates stress risers. Anodized 7075-T6 panels exposed to 5 % NaCl mist for 336 hours show no pits deeper than 10 µm; bare panels reach 80 µm pits. The oxide layer blocks chloride ion access to the base metal.
A honed cylinder bore with 0.3 µm Ra and 8° cross-hatch angle cuts ring friction by 12 W at 3000 rpm compared with a 1.2 µm turned bore. Oil consumption drops 18 % over 100 hours of dynamometer running.
TiN-coated H13 punch faces withstand 2200 MPa contact stress before coating fracture; uncoated H13 fails at 1600 MPa. Tool life in blanking 2 mm CR4 steel rises from 40 000 hits to 120 000 hits.
Stress-relief by vibratory finishing removes 60 % of machining residuals in thin 7075 plates. Warpage after a 120 °C cure cycle stays under 0.03 mm, versus 0.12 mm for as-machined plates.
A 2008 study machined AISI 1045 round bars on a CNC lathe with varied feeds, then applied grinding, honing, and shot peening. Rotating-bending fatigue at 350 MPa gave median lives of 1.1 × 10⁵, 1.4 × 10⁵, and 1.9 × 10⁵ cycles respectively. SEM images showed crack initiation delayed to 0.3 mm depth in peened samples versus 0.05 mm in ground samples.
A 2007 CIRP paper measured residual stresses by X-ray diffraction after face milling 7075-T7351. Tensile peaks of +180 MPa dropped to –420 MPa after laser peening. Endurance limit rose 32 % in fully reversed bending.
A 2015 investigation turned Ti-6Al-4V bars, then electropolished half the batch. Pin-on-disk wear against UHMWPE at 50 N load produced 0.018 mm³ debris per 10⁶ cycles for polished surfaces versus 0.042 mm³ for turned surfaces. Surface roughness fell from 0.85 µm Ra to 0.11 µm Ra.
Surface treatments turn the raw CNC finish into a controlled engineering layer. Mechanical compression, chemical barriers, and hard coatings each solve specific threats—fatigue, wear, or corrosion. Data from fatigue rigs, wear tracks, and corrosion chambers show gains of 20 % to 400 % in life, depending on load and environment. The choice starts with the alloy and duty cycle, then moves to cost and throughput. A ground-and-peened steel shaft, a hard-anodized aluminum bracket, or a nitrided gear all follow the same logic: measure the starting surface, pick the treatment that flips the failure mode, and verify with a short test series. The numbers pay for the equipment in months, not years.
Q1: Which treatment gives the fastest corrosion fix for stainless CNC parts?
A: Nitric acid passivation—30 minutes in 20 % solution restores the oxide film and passes 96-hour humidity tests.
Q2: Does shot peening change critical dimensions on tight-tolerance parts?
A: Edge rounding stays under 0.008 mm with 0.25 mm shot and 8A intensity; check with profilometer.
Q3: Can a coating quiet a high-speed spindle?
A: DLC on bearing races cuts vibration by 18 dB at 18 000 rpm and lowers heat rise 9 °C.
Q4: What payback period for hard anodizing aluminum housings?
A: $0.60 per part adds 4× life in marine air; payback in four months on 5000-unit runs.
Q5: How to confirm fatigue improvement in-house?
A: Run three-point bending on 10 samples at 60 % yield; plot cycles to crack with acoustic emission.
